| Brand Name : | SBN |
| Model Number : | SLG65/70/85/95/120/135 |
| Certification : | CE,SGS,BV |
| Price : | USD 30000 Set |
| Payment Terms : | L/C, T/T, Western Union |
| Supply Ability : | 10 set per month |
| Delivery Time : | Within 45 days after down payment |
1. animal feed production line instruction:
Operating easily all-automatic, Self cleaning to save manwork and
time, Sanitary food grade, Durable with a long life time.
You can make any shape of the pet feed according to different
market requirements. Perfect quality and excellent after-sales
service bring us good comments and confidence.
2. animal feed production line flow chart
Mixer-screw conveyor-twin screw extruder-air conveyor-dryer-air conveyor-oil sprayer-flavor roller-cooling machine
3. animal feed production line machine parameters
Model Parameter | FSJ-37 Miller | BFJ-Ⅱ Mixer | LXSL-I Screw conveyor | SLG65-III animal feed production line | FSJ-0.75 Air conveyor | KX-3-5D Dryer | FSJ-0.75 Air conveyer | PYJ-II Oil sprayer | GT-II Roller | LQSS-II Cooling conveyor |
Installed capacity (kw) | 15 | 4 | 0.75 | 36.0 | 1.1 | 27 | 0.75 | 10.0 | 1.5 | 2.2 |
Output (kg/h) | 300 | 150 | 150 | 150 | 150 | 150 | 150 | 100 | 300 | 260 |
Dimension (m) | 1.2×0.8×1.5 | 1.0×0.7×1.4 | 3.3×.8×2.3 | 2.7×0.9×1.9 | 3×.0.6×0.55 | 5.0×1.3×1.8 | 1.1×0.6×0.5 | 1.1×0.7×1.8 | 3..9×0..9×2.0 | 5.0×0.7×1.1 |
4. animal feed production line machine samples
Extruding system:
The working principle is forcing the ingredients forward to be
conveyed and extruded
in the sealed charging barrel by making use of the engaged twin
screws, at the same time, heating the ingredients through heating.cycles, the
ingredients are mixed, melt and sheared step by step under the conditions of high
temperature and pressure. At last the ingredients are inflated at the point of
being extruded out. This system possesses self-cleaning function.
Rotary-cutting system:
The ingredients are cut by high-speed rotary cutting-off knife when
they are extruded
and inflated. The length of cut-off is adjustable through step-less
speed regulating electrical machine.
Heating system:
The heating system is divided into several heating areas by means
of far-infrared heating cycles. The temperature of each area is automatically
adjusted through separate temperature controller.
Driving system:
This system is composed of primary electric motor, reductor,
distribution box, and
lubrication system. Adopting imported frequency controller, it
assures large regulating range, efficient power distribution, accurate adjustment, steady
working as well as prolonging the working life of the components.
Controlling system:
Adopting centralized controlling, the whole process, from starting,
rotary cutting,
lubricating, switching off to output adjustment can be
automatically operated.
Automatic defender and status display device are also allocated in
this system
Digital display for pressure control in extruding system and
temperature in heating system
Digital display for frequency control and speed of screw in driving
system
| Machine attributes: | |
| Brand Name | SBN |
| Type | Twin and single screw food extruder |
| Place of Origin | Shandong, China |
| Model No. | SLG |
| Application | animal feed production line |
| Voltage | 3 phase 380V/50HZ, Single phase 220V/50HZ(or design) |
| Powder(kw) | 60-200kw for a complete plant |
| Weight | 1000-9000kgs |
| Dimension(L*W*H) | 21*2.0*4.0 |
| Certification | CE,SGS, BV |
| Warranty | 12 months |
| Machine material | Food grade Stainless steel |
| Motor | Chinese brands, Siemens, ABB, etc |
| Inverter(Defaule Customer Options) | Delta(the most famous brand in Taiwan) |
| Trial production | Available |
| OEM | Yes |
| Payment terms | T/T, L/C OR NEGOTABLE |
| Packing details | De-rusting oil with plastic bags, wooden cases |
| Delivery details | 30 days after the order |
| Consult | free |
The oven is used to dry the products. The moister in the food which come out of the extruder is about 12-15%. With the dry of the dryer, the moister can get down below 8% and this is easy to be storage for long time.
For our dryer oven, there are have rock wool inside the dryer, have good leakproofness and insulation.
|
|
