| Brand Name : | SAIBAINUO |
| Model Number : | SLG65;SLG70;SLG85;SLG95;SLG120; |
| Certification : | CE BV SGS |
| Price : | US$10000-80000/SET |
| Payment Terms : | L/C, T/T, Western Union |
| Supply Ability : | 30 sets per month |
| Delivery Time : | 30 working days |
Cattle Horse Sheep Feed Processing Machine Stainless steel #304 Material
1. Feature And Advantage:
1). Driven by variable frequency motor, the feeder can be adjusted automatically within a certain scope according to the production;
2). The interlock device, outer machine discharging device and over-load protection device work together to ensure the safety and reliability;
3). Magnetic separation and removal mechanisms are configured to prevent the iron impurities from entering into the suppression of granulation chamber.
4). The cooking time and result are highly improved by the extended stainless steel feeding conditioner with the axial inlet steam.
5). The Circulating lubrication oil system is specially designed to ensure the bearings in good condition.
6). the ordinary conditioner, thermal insulation conditioner or double-shaft differential conditioner are options according to your requirements.
2. Raw Materials And Feed Pellet Product:
1) Cereals:soybean, maize,corn, grain,sorghum,corn flour , wheat flour , crop stalks (corn stalk, sorghum stalk, cotton, rape stalk, peanut seedling, sunflower stalk), chaff, grasses, shrubs,
2) Coarse fiber: wheat bran, corn stalk, soybean meal,grass meal,rice husk, grass, groundnut shell, cottonseed hull
3) Additives: molasses, vegetable oil, Amino acid, bone meal, vitamin.
3. Technology Parameters:
| Model Parameters | HKJ250 | SZLH320 | SZLH350 | SZLH420 | SZLH508 |
| Capacity (t/h) | 1-1.5 | 2-4 | 3-6 | 4-10 | 10-15 |
| Main Power(kw) | 22 | 37 | 55 | 110 | 132 |
| Conditioner Power(kw) | 2.2 | 2.2 | 2.2 | 5.5 | 7.5 |
| Feeder Power(kw) | 0.75 | 0.75 | 0.75 | 1.5 | 1.5 |
| Inside Dia(mm) | 250 | 320 | 350 | 420 | 508 |
| Pellet Size(mm) | 2-8 | 2-8 | 2-8 | 2-8 | 2-8 |
| Size(m) | 1.55*1.3*1.4 | 2.15*0.78*1.74 | 2.5*1*2 | 3.3*1.1*2.5 | 3.5*1.2*2.7 |
| Weight(T) | 1.2 | 2.1 | 2.6 | 3.3 | 4 |
| Note | Belt driven | Gear driven | |||
Different sizes can be customized to customer requirements.
4. Application Industrials:
Ring die animal feed pellet machine is widely used in large,medium and small aquaculture,grain feed processing plant,animal farms,poultry farms,individual farmers and small and medium sized farms,small feed mills to use.
Ring Die Feed Pellet Mill Use In SZLH-420 Feed Pellet Production Line:
All our animal feed pellet machines are approved by CE certification.
Animal feed pellet machine were packaged by plywood box.
Shandong Double Crane Machinery Manufacture Co., Ltd. was established in 2009 and is located in Leling city, Shandong Province. We are dedicated to the development and production of feed equipment, biomass energy equipment and organic fertilizer equipment. Our company employs 150 skillful personnel. Therefore, we can easily meet your requirements. Thanks to our powerful distribution network, our products are popular with customers in many countries. With rapid development, we have passed CE, SGS and ISO9001 certifications and won many honorary titles. To learn more about what we can do for you, contact us anytime. We look forward to establishing a good and long-term business relationship with you.
|
|
