Jinan Saibainuo Technology Development Co., Ltd
7 Years
| Ask Lasest Price | |
| Brand Name : | SBN |
| Model Number : | SLG65/SLG70/SLG85/SLG95/SLG120 |
| Certification : | CE SGS BV |
| Price : | USD 1000-USD 100000 |
| Payment Terms : | L/C, T/T, Western Union |
| Supply Ability : | 10 sets/month |
| Delivery Time : | 40-60 days |
New Automatic All Energy Usen Power Saved Pet Food Making Extruder Machine
1.Product introduction
New Automatic All Energy Usen Power Saved Pet Food Making Extruder
Machine
| Model | SLG65 | SLG70 | SLG85 | SLG95 |
| Install Power | 65KW | 110KW | 190KW | 250KW |
| Consumption Power | 42KW | 77KW | 133KW | 175KW |
| Output | 120-150KG/H | 220-260KG/H | 500-600KG/H | 900-1000KG/H |
| Dimension | 19000×1300×2200mm | 22000×1300×2200mm | 30000×1300×2500mm | 38000×1300×3000mm |
4. Extruding system:
The working principle is forcing the ingredients forward to be
conveyed and extruded
in the sealed charging barrel by making use of the engaged twin
screws, at the same time, heating the ingredients through heating-cycles, the
ingredients are
mixed, melt and sheared step by step under the conditions of high
temperature and pressure. At last the ingredients are inflated at the point of
being extruded
out. This system possesses self-cleaning function.
5.Display of machine products
| Machine attributes: | |
| Brand Name | SBN |
| Type | Twin and single screw food extruder |
| Place of Origin | Shandong, China |
| Model No. | SLG |
| Application | Fish feed processing line |
| Voltage | 3 phase 380V/50HZ, Single phase 220V/50HZ(or design) |
| Powder(kw) | 60-200kw for a complete plant |
| Weight | 1000-9000kgs |
| Dimension(L*W*H) | 21*2.0*4.0 |
| Certification | CE,SGS, BV |
| Warranty | 12 months |
| Machine material | Food grade Stainless steel |
| Motor | Chinese brands, Siemens, ABB, etc |
| Inverter(Defaule Customer Options) | Delta(the most famous brand in Taiwan) |
| Trial production | Available |
| OEM | Yes |
| Payment terms | T/T, L/C OR NEGOTABLE |
| Packing details | De-rusting oil with plastic bags, wooden cases |
| Delivery details | 30 days after the order |
| Consult | free |
|
|
